Carbon Steel DIN 17175 Pipes

Home > Carbon Steel > Carbon Steel DIN 17175 Pipes

Carbon Steel DIN 17175 Pipes Manufacturer, Supplier and Exporter in Indonesia, Jakarta

Bulan Pipes and Tubes stands out as a top-notch manufacturer and supplier of high-quality Carbon Steel DIN 17175 Pipes, proudly based in Jakarta, Indonesia. Known for its precision engineering and strict adherence to international standards, Bulan caters to a variety of industries with durable and dependable piping solutions. The company boasts an extensive selection of DIN 17175 carbon steel pipes, expertly designed to handle high pressure and temperature, making them perfect for boiler and heat exchanger applications. With a strong commitment to quality and timely delivery, Bulan Pipes and Tubes has built a solid reputation throughout Indonesia and the Southeast Asian region.

17175 Carbon Steel Thin Wall Pipe Supplier in Indonesia, DIN 17175 CS Pipe Exporter in Indonesia, 17175 Carbon Steel Pipe Sizes in mm, DIN 17175 CS Pipe Manufacturer in Surabaya, Carbon Steel DIN 17175 Pipes Price List in Bekasi, Large Diameter DIN 17175 Carbon Steel Pipe Distributor in Surabaya, Carbon Steel DIN 17175 Pipes in Bandung, Carbon Steel 17175 Pipes Supplier in Surabaya, DIN 17175 CS Pipes Distributor in Jakarta

The Carbon Steel DIN 17175 Pipes are primarily made up of carbon, manganese, phosphorus, sulfur, and silicon. These elements work together to give the steel its strength, hardness, and resistance to wear and corrosion. The mechanical properties include a tensile strength that ranges from 440 to 590 MPa and a yield strength of about 235 MPa, along with impressive elongation (≥25%) and impact resistance. These characteristics make DIN 17175 pipes a great choice for high-pressure environments, ensuring they maintain their structural integrity and longevity even under extreme temperature and pressure conditions.

Carbon Steel DIN 17175 Pipes Specification

Dimensions : ASTM, ASME and API
Standard : BS 3059
Outside Diameter : 5-90 mm
Wall Thickness : 0.5-15 mm
Length :in any length from 4 m to 12 m as per customer choice
Type :Seamless, Welded, ERW
End :Plain End, Beveled End, Treaded
Schedules :SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules

Carbon Steel DIN 17175 Pipes Chemical Composition

Grade		C	Si	Mn	S	P	Cr	Mo	V
Standard	Steel grade	C	Si	Mn	Max		Cr	Mo	V
DIN 17175	St35.8	=0.17	0.10-0.35	0.40-0.80	0.02	0.025	–	–	–
	St45.8	=0.21	0.10-0.35	0.40-1.2	0.02	0.025	–	–	–
	15Mo3	0.12-0.20	0.10-0.35	0.40-0.80	0.02	0.025	–	0.25-0.35	–
	13CrMo44	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.70-1.10	0.45-0.65	–
	10CrMo910	0.08-0.15	=0.50	0.40-0.70	0.02	0.025	2.00-2.5	0.90-1.20	–
	14MoV63	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.30-0.60	0.50-0.70	0.22-0.32
	12Cr1MoV	0.08-0.15	0.17-0.37	0.40-0.70	0.02	0.025	0.90-1.20	0.25-0.35	0.15-0.30

Carbon Steel DIN 17175 Pipes Mechanical Properties

Grade		C	Si	Mn	S	P	Cr	Mo	V
Standard	Steel grade	C	Si	Mn	Max		Cr	Mo	V
DIN 17175	St35.8	=0.17	0.10-0.35	0.40-0.80	0.02	0.025	–	–	–
	St45.8	=0.21	0.10-0.35	0.40-1.2	0.02	0.025	–	–	–
	15Mo3	0.12-0.20	0.10-0.35	0.40-0.80	0.02	0.025	–	0.25-0.35	–
	13CrMo44	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.70-1.10	0.45-0.65	–
	10CrMo910	0.08-0.15	=0.50	0.40-0.70	0.02	0.025	2.00-2.5	0.90-1.20	–
	14MoV63	0.10-0.18	0.10-0.35	0.40-0.70	0.02	0.025	0.30-0.60	0.50-0.70	0.22-0.32
	12Cr1MoV	0.08-0.15	0.17-0.37	0.40-0.70	0.02	0.025	0.90-1.20	0.25-0.35

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

ASME SA213 DIN 17175 Pipe Exporter in Jakarta, Carbon Steel DIN 17175 Pipes Price List in Indonesia, DIN 17175 CS Pipes Supplier in Indonesia, Carbon Steel DIN 17175 Pipes Exporter in Surabaya, DIN 17175 Carbon Steel Pipes Exporter in Surabaya, ASTM A213 Carbon Steel DIN 17175 Pipes Size Chart, Carbon Steel DIN 17175 Pipes Price in Bandung, DIN 17175 Carbon Steel Pipe Weight Chart, Schedule 40 DIN 17175 Carbon Steel Pipe Thickness, DIN 17175 Pipes Supplier in Bekasi, Carbon Steel DIN 17175 Pipes Stockist in Indonesia

Why Choose Carbon Steel DIN 17175 Pipes from Bulan Pipes and Tubes?

Choosing Carbon Steel DIN 17175 Pipes from Bulan Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Carbon Steel DIN 17175 Pipes Supplier in Indonesia, Jakarta

Bulan Pipes and Tubes is one of the largest Carbon Steel DIN 17175 Pipes suppliers in Indonesia, Jakarta, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.

Carbon Steel DIN 17175 Pipes Dimensions

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

ASTM A335 DIN 17175 Pipe Exporter in Jakarta, DIN 17175 Carbon Steel Pipe Price List in Indonesia, DIN 17175 CS Pipe Supplier in Indonesia, Carbon Steel DIN 17175 Pipes Exporter in Surabaya, Carbon Steel DIN 17175 Pipes Exporter in Surabaya, DIN 17175 Pipes Size Chart, 17175 Carbon Steel Pipe Price in Bandung, DIN 17175 Pipes CS Weight Chart, Carbon Steel DIN 17175 Pipes Thickness, CS DIN 17175 Pipes Supplier in Bekasi, 17175 Carbon Steel Thin Wall Pipe Stockist in Indonesia

Types of Carbon Steel DIN 17175 Pipes

Are Custom Sizes Available for Carbon Steel DIN 17175 Pipes?

Yes, we offer custom sizes for Carbon Steel DIN 17175 Pipes to meet your specific requirements. Our team at Bulan Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@bulanpipes.id.

Carbon Steel DIN 17175 Pipes Supplier in Indonesia, 17175 Carbon Steel Thin Wall Pipe Exporter in Indonesia, CS DIN 17175 Pipes Manufacturer in Surabaya, Carbon Steel DIN 17175 Pipes Price List in Bekasi, DIN 17175 Pipes Carbon Steel Distributor in Surabaya, 17175 CS Pipes in Bandung, DIN 17175 Pipes Supplier in Surabaya, Carbon Steel DIN 17175 Pipes Distributor in Jakarta, CS DIN 17175 Pipe Sizes in mm

These Carbon Steel DIN 17175 Pipes are widely utilized in high-temperature service applications, particularly in sectors like petrochemical, power generation, and oil and gas. They play a crucial role in constructing boilers, superheaters, heat exchangers, and pressure vessels, where high performance and durability are non-negotiable. Their ability to endure high pressure and thermal stress makes them ideal for transporting hot fluids and gases. Additionally, they find their place in refineries and chemical plants, delivering reliable performance in critical applications where strength, corrosion resistance, and thermal stability are essential.
