Carbon Steel IS 3589 Pipes Manufacturer, Supplier and Exporter in Indonesia, Jakarta

Based in Jakarta, Indonesia, Bulan Pipes and Tubes is a top producer and supplier of Carbon Steel IS 3589 Pipes, which are extensively utilised in the infrastructure and industrial sectors for gas, water and sewage applications. Our IS 3589 pipes are produced in accordance with the Indian Standard IS 3589 specifications, guaranteeing high performance under pressure, consistent quality, and dimensional accuracy. These pipes provide an affordable and long-lasting solution for structural, mechanical, and water transport applications. At Bulan, we provide reliable piping systems to both domestic and foreign markets with an emphasis on timely delivery and quality assurance.

IS 3589 Steel Pipe Supplier in Indonesia, IS 3589 Carbon Steel Pipes Exporter in Indonesia, IS 3589 Pipes Sizes in mm, IS 3589 CS Pipes Manufacturer in Surabaya, Carbon Steel IS 3589 Pipes Price List in Bekasi, CS IS 3589 Pipes Distributor in Surabaya, IS 3589 Carbon Steel Pipes in Bandung, IS 3589 CS Pipes Supplier in Surabaya, CS IS 3589 Pipes Distributor in Jakarta

The main constituents of Carbon Steel IS 3589 Pipes are sulphur (maximum 0.05%), manganese (0.3–0.9%), phosphorus (maximum 0.05%), and carbon (up to 0.25%). Depending on size and thickness, these pipes usually have a minimum yield strength of 240 MPa, a tensile strength between 410 and 510 MPa, and an elongation of 20% or more. The material’s toughness, impact resistance, and weldability are well-known. IS 3589 pipes are appropriate for structural and fluid-carrying applications because they are easy to fabricate and function well in moderate-pressure applications.

Carbon Steel IS 3589 Pipes Specification

Size in MM	15 Nominal Bore to 150 Nominal Bore
Dimension & Tolerance	Dimensions IS: 3589 = 2004 / Equivalent to BS = 1985/ 1387
Specifications	IS 3589
Surface Finish	Black
Pipe Marking	All Pipe are marked as follows: Supplier or Manufacturer’s Name, Standard, Grade, OD, Thickness, Length, Heat Number
Features	High Strength, Corrosion Resistant, Deformability & High Toughness
Length	As per Client’s requirement

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

IS 3589 Carbon Steel Pipes Exporter in Jakarta, Carbon Steel IS 3589 Pipes Price List in Indonesia, IS 3589 Pipes Supplier in Indonesia, Carbon Steel IS 3589 Pipes Exporter in Surabaya, IS 3589 Carbon Steel Pipes Exporter in Surabaya, IS 3589 CS Pipes Size Chart, IS 3589 Carbon Steel Pipes Price in Bandung, IS 3589 Pipes Weight Chart, IS 3589 CS Pipes Thickness, IS 3589 Carbon Steel Pipes Supplier in Bekasi, IS 3589 Pipes Stockist in Indonesia

Why Choose Carbon Steel IS 3589 Pipes from Bulan Pipes and Tubes?

Choosing Carbon Steel IS 3589 Pipes from Bulan Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Carbon Steel IS 3589 Pipes Sizes

Nominal Bore	Nominal Bore	Outer Diameter	Light		Medium		Heavy
Nominal Bore	Nominal Bore	Outer Diameter	Thickness	Weight	Thickness	Weight	Thickness	Weight
MM	IN	MM	MM	Kg/Meter	MM	Kg/Meter	MM	Kg/Meter
6	1/8″	10.32	1.80	0.361	2.00	0.407	2.65	0.493
10	3/8″	17.10	1.80	0.674	2.35	0.852	2.90	1.020
15	1/2″	21.43	2.00	0.952	2.65	1.122	3.25	1.450
20	3/4″	27.20	2.35	1.410	2.65	1.580	3.25	1.900
8	1/4″	13.49	1.80	0.517	2.35	0.650	2.90	0.769
25	1″	33.80	2.65	2.010	3.25	2.440	4.05	2.970
40	11/2″	48.40	2.90	3.250	3.25	3.610	4.05	4.430
50	2″	60.30	2.90	4.110	3.65	5.100	4.47	6.170
65	21/2′	76.20	3.25	5.840	3.65	6.610	4.47	7.900
80	3″	88.90	3.25	6.810	4.05	8.470	4.85	10.100
100	4″	114.30	3.65	9.890	4.50	12.100	5.40	14.400
125	5″	139.70	…..	……	4.85	16.200	5.40	17.800
150	6″	165.10	……	…….	4.85	19.200	5.40	21.200
Wall Thickness	7 Inch Nominal Bore 193.7 Kg/Meter	8 Inch Nominal Bore 219.1 Kg/Meter	10 Inch Nominal Bore 273 Kg/Meter	12 Inch Nominal Bore 323.7 Kg/Meter	14 Inch Nominal Bore 355.6 Kg/Meter	16 Inch Nominal Bore 406.4 Kg/Meter	18 Inch Nominal Bore 454 Kg/Meter	20 Inch Nominal Bore 508 Kg/Meter
9.53	……	51.50	60.24	73.75	81.21	93.13	105.00	117.00
4.85	22.59	25.62	32.07	38.13	……	……..	…….	…….
5.20	24.17	27.43	34.34	40.84	……	……..	……..	……..
5.60	26.00	29.28	36.93	43.93	48.11	……..	………	……….
7.01	32.27	36.76	46.43	55.45	61.82	69.04	……	……
7.94	…..	41.00	50.95	61.85	67.98	77.92	87.80	…….
6.35	29.34	33.28	41.73	49.67	54.43	62.35	70.50	78.50
6.00	27.88	31.53	39.50	47.02	51.49	61.00	69.00	……..
8.18	……	42.56	53.42	65.12	……	……	……	……
12.70	……	…..	……	……	107.28	123.30	139.00	155.00

Dimensions of IS 3589 Pipes

Nominal Bore		Outside Diameter		Light Thickness Weight		Medium Thickness Weight		Heavy Thickness Weight
Inch	MM	Inch	MM	MM	kg/Meter	MM	kg/Meter	MM	kg/Meter
1/8	3	0.406	10.32	1.80	0.361	2.00		2.65	0.493
1/4	6	0.532	13.49	1.80	0.517	2.35	0.407	2.90	0.769
3/8	10	0.872	17.10	1.80	0.674	2.35	0.852	2.90	1.02
3/4	20	1.094	27.20	2.35	1.410	2.65	1.580	3.25	1.90
1.1/2	40	1.906	48.40	2.90	3.250	3.25	3.610	4.05	4.43
1	25	1.312	33.80	2.65	2.010	3.25	2.440	4.05	2.97
1.1/4	32	1.656	42.90	2.65	2.580	3.25	3.140	4.05	3.84
1/2	15	0.844	21.43	2.00	0.952	2.65	1.122	3.25	1.45
2	50	2.375	60.30	2.90	4.110	3.65	5.100	4.47	6.17
2.1/2	65	3.004	76.20	3.25	5.840	3.65	6.610	4.47	7.90
6	150	6.500	165.10	–	–	4.85	19.20	5.40	21.2
3	80	3.500	88.90	3.25	6.810	4.05	8.470	4.85	10.1
4	100	4.500	114.30	3.65	9.890	4.50	12.10	5.40	14.4
5	125	5.500	139.70	–	–	4.85	16.20	5.40	17.8

Largest Carbon Steel IS 3589 Pipes Supplier in Indonesia, Jakarta

Bulan Pipes and Tubes is one of the largest Carbon Steel IS 3589 Pipes suppliers in Indonesia, Jakarta, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.

IS 3589 CS Pipes Supplier in Indonesia, Carbon Steel IS 3589 Pipes Exporter in Indonesia, IS 3589 CS Pipes Manufacturer in Surabaya, IS 3589 Carbon Steel Pipes Price List in Bekasi, CS IS 3589 Pipes Distributor in Surabaya, IS 3589 CS Pipes in Bandung, IS 3589 CS Pipes Supplier in Surabaya, Carbon Steel IS 3589 Pipes Distributor in Jakarta, IS 3589 Carbon Steel Pipes Sizes in mm

Types of Carbon Steel IS 3589 Pipes

Are Custom Sizes Available for Carbon Steel IS 3589 Pipes

Yes, we offer custom sizes for Carbon Steel IS 3589 Pipes to meet your specific requirements. Our team at Bulan Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@bulanpipes.id.

IS 3589 CS Pipes Exporter in Jakarta, Carbon Steel IS 3589 Pipes Price List in Indonesia, IS 3589 Pipes Supplier in Indonesia, CS IS 3589 Pipes Exporter in Surabaya, IS 3589 Pipes Exporter in Surabaya, IS 3589 Carbon Steel Pipes Size Chart, IS 3589 Pipes Price in Bandung, CS IS 3589 Pipes Weight Chart, IS 3589 Carbon Steel Pipes Thickness, IS 3589 CS Pipes Supplier in Bekasi, IS 3589 Pipes Stockist in Indonesia

Because of their strength and resistance to corrosion, carbon steel IS 3589 pipes are widely used in industrial fluid transportation, sewage lines, and water distribution. Power plants, municipal infrastructure, irrigation projects, and firefighting systems are all excellent uses for these pipes. They serve a variety of structural functions in construction, including pilings and columns. They are appropriate for mechanical applications, chemical plants, and oil refineries due to their high strength and weldability. Boiler feed lines and compressed air systems also favour IS 3589 pipes because they provide dependable performance and a long service life in a variety of industrial settings.
