Home > Copper Nickel > Copper Nickel Boiler Tubing
Bulan Pipes and Tubes, located in Jakarta, Indonesia, is a reputable manufacturer and supplier of top-notch Copper Nickel Boiler Tubing. With a keen emphasis on precision engineering and durability, Bulan provides tubing solutions tailored for marine, power generation, and industrial uses. Their Copper Nickel (Cu-Ni) boiler tubes are produced using cutting-edge technology and meet international standards such as ASTM B111 and B466. Renowned for their outstanding corrosion resistance, thermal conductivity, and long lifespan, Bulan Pipes and Tubes has become a trusted partner for industries in need of high-quality tubing throughout Indonesia and Southeast Asia.
Copper Nickel Boiler Tubing typically consists of 90% Copper (Cu) and 10% Nickel (Ni), with minor additions of iron (Fe) and manganese (Mn) to enhance strength and corrosion resistance. Common grades include Cu-Ni 90/10 (C70600) and Cu-Ni 70/30 (C71500). The mechanical properties showcase a tensile strength ranging from 310 to 500 MPa, yield strength between 105 and 220 MPa, and elongation of 30 to 45%. It boasts excellent resistance to seawater corrosion, biofouling, and thermal stress, making it perfect for high-temperature and saline environments like boilers and heat exchangers.
| Boiler Tube Standard | ASTM B552 / ASME SB552 |
| Seamless Boiler Tube Sizes | 1 / 2″ NB – 16″ NB |
| Welded Boiler Tube Sizes | 1 / 2″ NB – 24″ NB |
| Boiler Tube Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Boiler Tubes available Ex-stock |
| Boiler Tube Manufacturing Process | Seamless / Welded / ERW |
| Cupro Nickel Boiler Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Boiler Tube Length | Single Random, Double Random, Standard & Cut length |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Cupro Nickel Boiler Tubes, Finish as per customer Requirements |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Properties | Imperial | Metric |
|---|---|---|
| Yield strength (depending on temper) | 40000-76000 psi | 276-524 MPa |
| Shear modulus | 6380 ksi | 44.0 GPa |
| Tensile strength | 38000-77000 psi | 262-531 MPa |
| Elongation at break (in 50.8 mm) | 46% | 46% |
| Poisson’s ratio | 0.34 | 0.34 |
| Elastic modulus | 17000 ksi | 117 GPa |
| Machinability (UNS C36000 (free-cutting brass) = 100) | 20 | 20 |
| Designation | Chemical Composition % | ||||||||
| Cu | Sn | Al | As | Ni | Fe | Mn | Pb max. | Zn | |
| C70400 | Rem | – | – | – | 4.8-6.2 | 1.3-1.7 | 0.3-0.8 | 0.05 | 1.0max |
| Property |
Metric Units |
Imperial Units |
|---|---|---|
|
Melting Point (Liquidus) |
11,500°C |
21,000°F |
|
Melting Point (Solidus) |
11,000°C |
20,100°F |
|
Density |
8.94 gm/cm³ @ 20°C |
0.323 lb/in³ @ 68°F |
|
Specific Gravity |
8.94 |
8.94 |
|
Coefficient of Thermal Expansion |
17.1 x 10 -6 / °C (20-300°C) |
9.5 x 10 -5 / °F (68-392°F) |
|
Themal Conductivity |
40 W/m. °K @ 20°C |
23 BTU/ft³/ft/hr/°F @ 68°F |
|
Thermal Capacity (Specific Heat) |
380 J/kg. °K @ 20°C |
0.09 BTU/lb/°F @ 68°F |
|
Electrical Conductivity (Annealed) |
5.26 microhm?¹.cm?¹ @ 20°C |
9.1% IACS |
|
Electrical Resistivity (Annealed) |
0.190 microhm.cm @ 20°C |
130 ohms (circ mil/ft) @ 68°F |
|
Modulus of Elasticity (tension) |
140 GPa @ 20°C |
20 x 10 6 psi @ 68°F |
|
Modulus of Rigidity (torsion) |
52 GPa @ 20°C |
7.5 x 10 6 psi @ 68°F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Copper Nickel Boiler Tubing from Bulan Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Tube is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Choose Copper Nickel Boiler Tubing from Bulan Pipes and Tubes for its superior seawater corrosion resistance, biofouling protection, and excellent thermal conductivity, making it ideal for marine, industrial, and coastal applications requiring long-lasting performance and reliability.
Yes, we offer custom sizes for Copper Nickel Boiler Tubing to meet your specific requirements. Our team at Bulan Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@bulanpipes.id.
Copper Nickel Boiler Tubing is extensively utilized in industries where resistance to seawater and brine solutions is crucial. Its applications span across boilers, condensers, heat exchangers, desalination plants, offshore oil and gas platforms, shipbuilding, and power plants. Thanks to its remarkable thermal conductivity and anti-fouling properties, it’s an excellent choice for marine boilers and systems that face harsh conditions. Cu-Ni boiler tubing is also favored for cooling systems, evaporators, and other essential components that require high corrosion resistance and mechanical stability under varying thermal loads, ensuring a longer operational life and lower maintenance costs.
