Brydon Pipes & Tubes, Jakarta, Indonesia, is a renowned manufacturer and supplier of high-performance piping solutions such as Incoloy 800, 800H, and 800HT pipes. Nickle-iron-chromium alloys, these are specifically designed to resist high-temperature oxidation and carburization, making them perfect for challenging industrial applications like petrochemical processing, power generation, and heat exchangers. Our Incoloy pipes are offered in a diverse array of sizes and specifications to deliver precision and reliability under harsh environments. With a focus on quality, Brydon provides reliable and long-lasting pipe solutions with excellent performance under severe service conditions.
Incoloy 800, 800H, and 800HT pipes consist of nickel-iron-chromium alloys with 30–35% nickel, 19–23% chromium, and minute traces of titanium and aluminum. These alloys have superior oxidation, carburization, and high-temperature corrosion resistance. They have tensile strength of 550–690 MPa (80–100 ksi) and good ductility and structural stability. The H and HT forms have enhanced creep and stress rupture properties because of carbon and grain size control. These aspects recommend them for high-temperature service in aggressive and corrosive industrial processes, particularly where thermal stability is a requirement.
Alloy 800 Pipe Specification | ASTM B 167 ASME SB 167 / ASTM B 829 ASME SB 829 / ASTM B 517 ASME SB 517 |
---|---|
Incoloy Alloy 800 Pipe Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
Our Presence | USA, Canada, Australia, Jakarta, Malaysia, Poland, Iran, Italy, Singapore, UAE |
Incoloy 800 Welded Pipe size | 5.0 mm – 1219.2 mm |
Alloy 800 EFW Pipe size | 5.0 mm – 1219.2 mm |
Specialized in | Large Diameter Alloy 800 Pipe |
Incoloy 800 Pipe Form | Hollow, Square, Round, Rectangular , Straight Pipes, Hydraulic Etc. |
Alloy 800 Pipe End | Plain End, Beveled End, Treaded. |
Incoloy 800 Pipe Length | Single Random, Double Random & Cut Length. |
Alloy 800 Seamless Pipe size | 4 to 219mm W. T.: 0.5 to 20mm |
Marking | All Incoloy Alloy 800 Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
Manufacturers of Incoloy 800 Pipe |
|
Incoloy 800 Pipe Schedule | SCH5, SCH10, SCH40, STD, SCH80, SCH160 |
Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2 |
Test |
|
Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
Grade | C | Mn | Si | Fe | S | Cr | Al-Ti | Ni | |
Incoloy 800 Pipe | min. | – | – | – | 39.5 | – | 19.0 | 0.15 | 30.0 |
max. | 0.1 | 1.5 | 1.0 | – | 0.015 | 23.0 | 0.60 | 35.0 | |
Incoloy 800H Pipe | min. | 0.05 | – | – | 39.5 | – | 19.0 | 0.15 | 30.0 |
max. | 0.1 | 1.5 | 1.0 | – | 0.015 | 23.0 | 0.60 | 35.0 | |
Incoloy 800HT Pipe | min. | 0.06 | – | – | 39.5 | – | 19.0 | 0.85/0.25 | 30.0 |
max. | 0.1 | 1.5 | 1.0 | – | 0.015 | 23.0 | 1.20/0.60 | 35.0 |
Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
800-H-HT | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa –205 | 30 | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Incoloy 800/800H/800HT Pipes from Bulan Pipes and Tubes ensures superior corrosion resistance, excellent thermal conductivity, high strength, and long-lasting performance. Our commitment to quality and precision makes our pipes and tubing ideal for demanding industrial applications.
Bulan Pipes and Tubes is the largest supplier of Incoloy 800/800H/800HT Pipes in Indonesia, Jakarta. We offer premium-quality, corrosion-resistant pipes and tubing ideal for marine, chemical, and industrial applications, with our reliable delivery and customized solutions to meet diverse client needs.
Yes, custom sizes are available for Incoloy 800/800H/800HT Pipes to meet specific requirements. These pipes can be tailored for various industrial applications. For more details, contact us at sales@bulanpipes.id.
Incoloy 800, 800H, and 800HT tubing is widely applied for high-temperature use because they possess excellent resistance to carburization, oxidation, and thermal stress. The alloys are widely utilized in petrochemical and chemical processing industries in the form of equipment like heat exchangers, furnace parts, and piping for transfer. They are utilized in the power generation industry in steam generators, superheaters, and nuclear reactor equipment because they have better thermal stability. The oil and gas industry also depends on these pipes for high-temperature, high-pressure applications needing long-term service under harsh environmental conditions. Their dependability makes them a vital selection in mission-critical applications.
