Home > Stainless Steel Tubing > Stainless Steel 202 Tubing
Bulan Pipes and Tubes, Jakarta, Indonesia, is one of the prominent producers and exporters of Stainless Steel 202 Tubing, providing tough, affordable, and high-performance tubing solutions. Made to international quality levels, our SS 202 tubing is suitable for a broad variety of structural and ornamental uses. Being an austenitic stainless steel, 202 is known for its fair toughness, moderate corrosion resistance, and superior formability—providing a versatile choice for industries in need of balancing performance and cost. Through stringent quality control and the latest manufacturing technologies, Bulan guarantees uniform product strength, reliability, and beauty in every shipment.
Stainless Steel 202 Tubing contains about 17–19% Chromium, 4–6% Nickel, and high Manganese (7.5–10%), with impurities of Carbon, Silicon, Nitrogen, and Phosphorus. It shows average corrosion resistance, particularly in indoor or weakly corrosive environments. The major mechanical properties are tensile strength of ~515 MPa, yield strength of ~275 MPa, and elongation of 40%, offering good performance in low- to medium-stress applications. While having lower corrosion resistance than 304, SS 202 tubing outperforms in work-hardening, weldability, and cold toughness, which makes it well suited for general-purpose industrial and architectural applications.
Standard | ASTM, AISI, GB, JIS, customers’ requests available |
Size | Round Tube: OD: 16-119mm or customized |
Thickness | 0.25mm-3.0mm |
Length | 6m or according to customers’ request |
Sample | Free sample is available, but freight should be paid by you |
Tolerance
| Outer diameter: ±0.2mm |
Thickness: ±0.05mm | |
Length: ±0.5mm | |
Ends | In plain end or bevelled ends or as your requirements |
Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing
| A. Sanded |
B. Gloss #400,Mirror #600 – #1000 | |
C. Brushed | |
D. Wood Grain | |
E. Embossed, Threaded | |
Application | Decorations, constructions, food industry, etc. |
Certification | ISO, SGS |
Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
Length | 6m or according to customer’s request |
Outer diameter | 6.35-219mm |
Tolerance | Outer diameter :±0.2mm |
Thickness :±0.02mm | |
Length :±0.5mm | |
Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Element | Content (%) |
|---|---|
| Iron, Fe | 72 |
| Chromium, Cr | 16.0 – 18.0 |
| Manganese, Mn | 5.50 – 7.50 |
| Nickel, Ni | 3.50 – 5.50 |
| Silicon, Si | 1.0 |
| Nitrogen, N | 0.25 |
| Carbon, C | 0.15 |
| Type | Yield Strength 0.2% offset (KSI) | Tensile Strength (KSI) | % Elongation (2″ Gauge length) | Hardness Rockwell |
|---|---|---|---|---|
| SS 201 Ann | 38 min. | 75 min. | 40% min. | HRB 95 max. |
| SS 201 ¼ Hard | 75 min. | 125 min. | 25.0 min. | 25 – 32 HRC (typical) |
| SS 201 ½ Hard | 110 min. | 150 min. | 18.0 min. | 32 – 37 HRC (typical) |
| SS 201 ¾ Hard | 135 min. | 175 min. | 12.0 min. | 37 – 41 HRC (typical) |
| SS 201 Full Hard | 145 min. | 185 min. | 9.0 min. | 41 – 46 HRC (typical) |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Stainless Steel 202 Tubing from Bulan Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Bulan Pipes and Tubes, a leading supplier of Stainless Steel 202 Tubing in Indonesia, Jakarta, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Bulan Pipes and Tubes, we provide custom sizes of Stainless Steel 202 Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
Stainless Steel 202 Tubing finds extensive use in applications requiring cost-effective strength, moderate corrosion resistance, and appearance. It is used in railings, architectural trim, furniture, kitchen equipment, and automotive interiors. Structural applications also encompass light-duty frames, window and door supports, and decorative trim in residential and commercial buildings. The tubing‘s high weldability and formability also place it ideally for fabrication-intensive applications. Though not for use in marine or severely corrosive exposures, 202 tubing is a dependable performer in clean, dry, and indoor environments—providing long-term value where economy meets functionality.
