Home > Stainless Steel > Stainless steel 310H Welded Tubing
Bulan Pipes and Tubes stands out as a top-notch manufacturer and supplier of high-performance stainless steel solutions right from Jakarta, Indonesia. Our Stainless Steel 310H Welded Tubing is meticulously crafted to meet the demands of critical industries that need exceptional resistance to high temperatures and corrosion. Produced under strict quality control measures, our welded tubing boasts impressive strength, durability, and precise dimensions. With a commitment to reliability and customer satisfaction, Bulan Pipes and Tubes serves both local and international markets, delivering tubing solutions that comply with ASTM and global standards for pressure, structural, and high-temperature applications.
Stainless Steel 310H Welded Tubing is an austenitic chromium-nickel alloy with a higher carbon content, specifically designed for high-temperature applications. Its chemical makeup features around 25% chromium and 20% nickel, which boosts oxidation resistance and maintains structural integrity during thermal cycling. The increased carbon content enhances strength at elevated temperatures. Typically, its mechanical properties include a minimum tensile strength of 515 MPa, yield strength of 205 MPa, and an elongation of 40%. With outstanding creep resistance and hardness, 310H welded tubing is perfect for challenging environments with high temperatures and aggressive atmospheres.
| 310H Stainless Steel Tube Finish | Polished, BA (Bright & Annealed),AP (Annealed & Pickled), MF |
|---|---|
| Stainless Steel 310H Tube Standards | ASTM A213,ASTM A269, ASTM A249,ASME SA213,ASME SA269, ASME SA249, NACE MR0175/ISO 15156, PED 97/23/EC,EN 10216-5 TC1 / TC2, AD 2000 |
| Stainless Steel 310H Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| 310H stainless steel tubing End | Plain End, Beveled End, Treaded, Ends are suitable for orbital welding |
| Marking | All 310H Stainless Steel tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Stainless Steel 310H Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Stainless Steel 310H tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Stainless Steel 310H tube Form | Straight or ‘U’ bent Tubes, Round,Boiler, Coil , LSAW Tubes, Square, Hydraulic, Rectangular, Hollow Etc. |
| Stainless Steel 310H Tube Type | EFW, Seamless , Fabricated, ERW, Welded |
| SS 310H tube Length | Single Random , Standard & Cut length , Double Random |
| Non-Electropolished | (CFOS) Cleaned for Oxygen Grade Service or Corrosive Systems, (BA) Bright Annealed or (AP) Annealed & Pickled for High-Purity |
| I.D. Surface Finish Options | 5, 7 & 10 µin. Ra |
| 310H stainless steel tubing Testing & Inspection | Visual inspection • Surface roughness measurement • Helium-leak testing • Scanning Electron Microscopy (SEM) • Auger Electron Microscopy (AES) • Election Spectroscopy for Chemical Analysis (ESCA or XPS) • Particle testing • Moisture testing |
| Tolerances | In accordance with: ASTM: A269 & A632, JIS: G 3459 |
| 310H stainless steel tubing Test Certificate | Laboratory Test Certificate from Govt. Approved Lab. Manufacturer Test Certificate according to EN 10204 3.1 B Under Third Party Inspection |
| Electropolished | (EP) Electropolished for Ultra High Purity Systems |
| 310H stainless steel tubingApplication | Oil Tube , Boiler and Heatexchange , Gas Tube, Fluid Tuber |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 310H | min. | 0.04 | – | – | – | – | 24.0 | – | 19.0 | – |
| max. | 0.10 | 2.0 | 1.0 | 0.045 | 0.030 | 26.0 | 21.0 | – | ||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 310H | 515 | 205 | 40 | 95 | 217 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Stainless Steel 310H Welded Tubing from Bulan Pipes and Tubes for exceptional corrosion resistance, superior strength and excellent durability. Ideal for a variety of industrial applications it provides outstanding performance in harsh environments. With precision manufacturing and quality assurance, we ensure reliable and durable tubing solutions.
Bulan Pipes and Tubes is the largest supplier of Stainless Steel 310H Welded Tubing in Indonesia, Jakarta. Known for its high-quality products. We offer superior corrosion resistance, strength, and durability. Trusted by industries worldwide they provide reliable precision-engineered tubing for various applications and project needs.
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 310H | S31009 | – | X5CrNi18-10 | 2332 | SUS 310H | ||
Yes, Bulan Pipes and Tubes offer large custom designs for Stainless Steel 310H Welded Tubing. With design, wall thickness and length. Their adjustable options ensure the tubing meets specific application requirements. This flexibility makes it more efficient and reliable for different industries and environments. For more details, contact us at sales@bulanpipes.id.
Stainless Steel 310H Welded Tubing finds extensive use across various industries, including petrochemical, power generation, heat treatment, and thermal processing. Its remarkable high-temperature strength and oxidation resistance make it ideal for furnace components, heat exchangers, radiant tubes, and combustion chambers. In the chemical processing field, it effectively endures carburizing and reducing environments. Additionally, it plays a vital role in oil and gas refineries, cement plants, and aerospace applications where thermal stability is essential. The tubing’s robust mechanical properties ensure it meets the rigorous demands of these high-stakes environments.
