Stainless Steel 317 Pipes

Home > Stainless Steel > Stainless Steel 317 Pipes

Stainless Steel 317 Pipes Manufacturer, Supplier and Exporter in Indonesia, Jakarta

Bulan Pipes and Tubes stands out as a top manufacturer and supplier of Stainless Steel 317 Pipes, proudly based in Jakarta, Indonesia. Renowned for providing high-quality stainless steel piping solutions, Bulan specializes in corrosion-resistant alloys tailored for tough industrial settings. The Stainless Steel 317 pipes are particularly known for their exceptional resistance to chemical attacks, especially in acidic and chloride-heavy environments, making them perfect for process piping systems. With a strong commitment to international quality standards, timely deliveries, and customer satisfaction, Bulan serves a variety of industries, including chemical processing, pharmaceuticals, pulp and paper, and marine. Their products are designed to ensure long-lasting performance and reliability.

317 Stainless Steel Pipes Exporter in Jakarta, SS UNS S31700 Pipes Exporter in Indonesia, 317 Stainless Steel Pipe Manufacturer in Surabaya, SUS 317 Pipes Price List in Bekasi, ASTM A312 Stainless Steel 317 Pipe Supplier in Surabaya, Stainless Steel 1.4449 Pipes in Bandung

Stainless Steel 317 Pipes are crafted from a high-alloy austenitic stainless steel that contains about 18–20% chromium, 11–15% nickel, 3–4% molybdenum, and a maximum of 0.08% carbon. This unique blend significantly boosts resistance to pitting, crevice corrosion, and chemical attacks, particularly in acidic conditions. On the mechanical side, SS 317 boasts a tensile strength of around 515 MPa and a yield strength of about 205 MPa. It also offers good ductility, excellent weldability, and a melting range of 1370–1398°C. These characteristics make SS 317 pipes ideal for high-temperature applications and aggressive industrial environments that demand long-lasting strength and corrosion resistance.

Stainless Steel 317 Pipes Specification

Specifications	ASTM A312, A358 / ASME SA312, SA358
Outside Diameter	6.00 mm OD up to 914.4 mm OD, Sizes up to 24″ NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Thickness Range	0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type	Seamless / ERW / Welded / Fabricated / CDW
Form	Round Pipes, Square Pipes, Rectangular Pipes
Length	Single Random, Double Random & Required Length
End	Plain End, Beveled End, Treaded
Outside Finish	2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Delivery Condition	Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
EN 10216-5	EN 10216 317/317L Seamless Steel Pipe, EN 10216-5 1.4449 / 1.4438 Seamless Steel Pipes for pressure purposes
EN 10217-7	EN 10217 317/317L Welded Steel Pipe, Steel EN 10217-7 1.4449 / 1.4438 Welded Pipes for pressure purposes

Stainless Steel 317 Pipes Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	N
317	0.08 max	2 max	1 max	0.040 max	0.03 max	18 – 20	3 – 4	11 – 14	–

SS 317 Pipes Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
7.9 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

SS 317 Schedule 40 Pipe Price List in Indonesia, Stainless Steel S31700 Pipes Supplier in Indonesia, SS 317 Pipes Supplier in Jakarta, ASTM A312 Stainless Steel 317 Pipe Exporter in Surabaya, AISI 317 Pipes Exporter in Surabaya, 1 inch SS 317 Pipe Price in Bandung, SS 317 Pipe Weight Chart, SS 317 Schedule 20 Pipe Thickness, 317 Austenitic Stainless Steel Pipe Supplier in Bekasi

Why Choose Stainless Steel 317 Pipes from Bulan Pipes and Tubes?

Choosing Stainless Steel 317 Pipes from Bulan Pipes and Tubes offers excellent corrosion resistance, making it ideal for harsh environments. Our pipes are manufactured to the highest standards, making them durable and reliable. We provide customized solutions to meet the specific needs of the business. With competitive pricing and exceptional customer service, we guarantee a smooth shopping experience. Trust Brydon for your piping needs and enjoy unparalleled performance and longevity.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Stainless Steel 317 Pipes Supplier in Indonesia, Jakarta

Bulan Pipes and Tubes, one of the largest suppliers of Stainless Steel 317 Pipes in Indonesia, Jakarta, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.

Stainless Steel 317 Pipes Sizes in MM

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

ASME SA 312 TP317 Pipes Surabaya, Stainless Steel 317 Pipes Supplier in Bekasi, 317 Stainless Steel Pipes Exporter in Surabaya, SS UNS S31700 Pipes Supplier in Indonesia, SS 317 Schedule 20 Pipe Exporter in Bandung

Types of Stainless Steel 317 Pipes

Are Custom Sizes Available for Stainless Steel 317 Pipes?

Yes, we offer custom sizes for Stainless Steel 317 Pipes to meet your specific requirements. Our team at Bulan Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@bulanpipes.id.

SS UNS S31700 Pipes Exporter in Bandung, SUS 317 Pipes Supplier in Indonesia, 317 SS Pipes Manufacturer in Surabaya, 317 Austenitic Stainless Steel Pipe Dealer in Indonesia, Stainless Steel S31700 Pipes Manufacturer in Surabaya, SS 317 Pipe Supplier in Bekasi

Stainless Steel 317 Pipes find extensive use in industries that prioritize exceptional corrosion resistance and mechanical strength. They excel in managing acidic and high-chloride environments, making them a go-to choice for chemical processing plants, pulp and paper industries, pharmaceutical manufacturing, food and beverage processing, and marine applications. You’ll often see these pipes in heat exchangers, condensers, evaporators, and piping systems that transport corrosive liquids or gases.
